The new Little Mark IV amps add some amazing features to our flagship Markbass Little Mark III amplifier, an industry standard for tone, portability and value. This 300W version is a smart choice for those who don't need the full power of a 500W head. It offers new features such as the new bi-band limiter that responds faster and more dynamically to your playing, a mute switch, and a 3 way rotary-switch that includes the options of a Flat, Scooped or FSW (Footswitchable) EQ options.
TECHNICAL DETAILS
INPUTS
INPUT impedance: 1 Mohm, max. voltage: 9 Vpp
RETURN impedance: 22 Kohm, max. voltage: 10 Vpp
CONTROLS
GAIN 46 dB to +23 dB range
LINE OUT level control on front panel
PRE/POST EQ (for line out) switch on rear panel
GROUND LIFT switch on rear panel
MUTE SWITCH
MASTER VOLUME
EQUALIZATION
LOW center frequency 68 Hz; level: ±16 dB
MID LOW center frequency 360 Hz; level: ±16 dB
MID HIGH center frequency 800 Hz; level: ±16 dB
HIGH center frequency 10 kHz; level: ±16 dB
OLD SCHOOL max cut range: 250 Hz 20 kHz
3 WAY SWITCH flat/scooped-mid/FSW
OUTPUTS
SEND EFFECTS unbalanced, max. voltage 20 Vpp
TUNER OUT unbalanced, max. voltage 2 Vpp
LINE OUT balanced XLR, max. voltage 20 Vpp
SPEAKER OUT speakon/1/4 combo, 1/4*
*Little Mark IV Ninja : only speakon
OTHERS
HEIGHT 2 rack units (3.27 in. / 83 mm)
WIDTH 10.87 in. / 27.6 cm (19 in. / 48.3 cm with rack ears)
DEPTH 9.84 in. / 25 cm
WEIGHT 4.85 lbs / 2.2 kg
LIMITER
FOOTSWITCH (OPTIONAL) FLAT/SCOOPED-MID/FSW
OUTPUT POWER 300W RMS @ 4 ohm, 150W RMS @ 8 ohm
