Yamaha DTX10K-MBF Electronic Drum Kit, Mesh Heads
Double Kick Pedal NOT INCLUDED
SKU: M00001751
"DTX flagship model that boasts the beauty of real drums"
The DTX10 series is the flagship of the DTX lineup, combining the functionality of electronic drums with the sheer beauty of their acoustic counterparts.
Featuring real drum sounds and real room ambience recorded in world renowned studios, playability that allows you to create sounds intuitively, inspiring feel and expressiveness, and the true beauty of real birch shells with the same finishes used on acoustic drums, the DTX10 series was born from the technology and sensibilities that Yamaha has cultivated over its many years of crafting drums.
Pad sets
Snare
Tom Pad
Floor Tom Pad
Kick Pad
Hi-hat Pad
Crash cymbal 1
Crash cymbal 2
Ride cymbal
Hi-hat Stand
Footprint (average)
Weight
Pad Sets
Snare Stand
| DTX10K-X Real Wood / Black Forest | DTX10K-M Real Wood / Black Forest | ||
|---|---|---|---|
| Snare | XP125SD-X (12 inch TCS pad with 2 zone) | XP125SD-M (12 inch Mesh pad with 2 zone) | |
| Tom Pad | XP105T-X (10 inch TCS pad with 2 zone) | XP105T-M (10 inch Mesh pad with 2 zone) | |
| Floor Tom Pad | XP125T-X (12 inch TCS pad with 2 zone) | XP125T-M (12 inch Mesh pad with 2 zone) | |
| Kick Pad | KP128 (12 inch Mesh pad with Multi layer cushion) | KP128 (12 inch Mesh pad with Multi layer cushion) | |
| Hi-hat Pad | RHH135 (13 inch pad with 2 zone) | RHH135 (13 inch pad with 2 zone) | |
| Crash cymbal 1 | PCY135 (13 inch pad with 3 zone) | PCY135 (13 inch pad with 3 zone) | |
| Crash cymbal 2 | PCY155 (15 inch pad with 3 zone) | PCY155 (15 inch pad with 3 zone) | |
| Ride cymbal | PCY175 (17 inch pad with 3 zone) | PCY175 (17 inch pad with 3 zone) | |
| Hi-hat Stand | HS740A | HS740A | |
| Footprint (average) | 1,100 mm x 1,600 mm | 1,100 mm x 1,600 mm | |
| Weight | 46.77 kg | 42.1 kg | |
| Snare Stand | SS662 (Snare Stand for 12") | SS662 (Snare Stand for 12") | |
Tone generator
Dimensions
Width
Height
Depth
Weight
Maximum Polyphony
Effects
Drum kits
Voices
Click
Click Sets
Tempo
Time signatures
Subdivisions
Others
Training
Types
Songs
Audio Files
Import limit
Maximum loadable sample time
sample format
Recorder
Recording time
Internal memory
USB flash drive
Format
Other
Connectors
DC IN
Headphones
AUX IN
Output
USB
MIDI
Trigger Input
Bluetooth
Display
Accessories
| Tone Generator | ||
|---|---|---|
| Dimensions | Width | 342 mm (13-7/16 in) |
| Height | 196 mm (7-11/16 in) | |
| Depth | 66 mm (2-5/8 in) | |
| Weight | 2.0 kg (4 lb 7 oz) | |
| Maximum Polyphony | 256 notes | |
| Effects | For each Inst: EQ / Comp / Transient / Insertion (*1), For each Kit: Ambience / Effect 1 / Effect 2 and Master Comp / Master Effect, For overall: Master EQ / Phones EQ (*1) Insertion effects can be used only for specific Inst. | |
| Drum kits | Preset: 70 Kits, User: 200 Kits | |
| Voices | 733 | |
| Click Sets | 30 | |
| Tempo | 30 to 300 BPM, Tap Tempo supported. Voice guide | |
| Time signatures | 1/4 to 16/4, 1/8 to 16/8, and 1/16 to 16/16 | |
| Subdivisions | Accents, quarter notes, eighth notes, sixteenth notes, and eight-note triplets | |
| Others | Individual click volume control, wav import, timer | |
| Types | 10 | |
| Songs | Preset: 37 songs, User: 1 song | |
| Import limit | 1,000 files | |
| Maximum loadable sample time | 50 minutes 40 seconds (44.1 kHz, 16 bit, mono), 25 minutes 20 seconds (44.1 kHz, 16 bit, stereo) | |
| sample format | WAV | |
| Recording time | Internal memory | Maximum of 90 seconds |
| USB flash drive | Maximum of 90 minutes per file | |
| Format | Record/playback: WAV (44.1 kHz, 16 bit, stereo) | |
| Connectors | DC IN | DC IN (+12V) |
| Headphones | Headphones (standard stereo phone jack ×1, stereo mini jack ×1) | |
| AUX IN | AUX IN (stereo mini jack ×1, stereo standard phone jack ×1) | |
| Output | OUTPUT L/MONO, R (standard phone jack, one for each), INDIVIDUAL OUTPUT 1/2, 3/4, 5/6, 7/8 (stereo standard phone jack, one for each) | |
| USB | USB TO DEVICE, USB TO HOST | |
| MIDI | MIDI OUT ×1, MIDI IN ×1 | |
| Trigger Input | Trigger input jack ×10 (standard stereo phone jack, not including the HI-HAT CONTROL jack. 1, 14 for All type of pad, 2, 4, 6 for 2zone, 8, 9, 10 for 3zone, 11 dedicated for hi-hat pad/controllar, 12 for kick, 2zone) *If other pad is connected to each of the above terminals, it will operate as a 1-zone pad. *Maximum 14 of pads to be connected (when Y-cable is used) | |
| Bluetooth | Audio (varies by country) | |
| Display | Full Dot LCD (128×64 dot) | |
| Accessories | AC adaptor (PA-150 or an equivalent recommended by Yamaha (Output : DC 12V, 1.5 A))(*2), Owner’s Manual , module holder, module holder wing bolts (× 4), Cubase AI Download Information (*2) May not be included depending on your area. Check with your Yamaha dealer. | |
| SKU | M00001751 |
| Model # | DTX10K-MBF |
| Brand | Yamaha |
